ingersoll rand direct air compressors 10bar 18.5kw 25hp Direct Driven rotary screw type air compressor price China Factory

  • Product Item：YD-25A
  • motor power: 18.5kw/15hp
  • cooling method: air cooling
  • warranty: 5years for the air end and 2years for the whole compressor
  • Air Flow (m³/min)：2.3-3.1
  • Category：Products
    • Inquiry Send Email

    Description



    Features:

    1. driven type: belt driven;

    2. cooling method: air cooling;

    3. imported air end with high efficiency;

    4. bearing: SKF;

    5. motor protection: IP54/55;

    6. insulation class: F;

    7. noise: 65dB;

    8. exhausting oil content: ＜3ppm；

    9. voltage: 380/220/415V;

    10. air pressure: 7/8/10/13bar;

    11. air capacity: 1.8/1.65/1.5/1.3m³/min.

    Advantages

    1 . Air end with high-efficiency

    2. Double Screw with low noise, Super Silenced Enclosure

    3. Elegant compact design. Fully open access door to inner parts for easy service.

    4. 100% Continuous duty operation. Load/No Load operation

    5. High quality CE Certificate industrial electric motors. ISO,CE,UL Certificate

    6. Easy to use and read LCD control panel

    7. High temperature, high pressure and anti-rotation shutdown

    8. Energy efficient operation

    9. 5 micron, water-resistant air filtration material

    10. 2 year full machine warranty,5years air end warranty.

    11. Supply the machine with different working voltage according to customer's request,
    such as:

    220Volt,single phase,60hz/50hz
    220Volt,3 phase,60hz / 50hz

    380Volt,3phase,50hz
    440Volt,3phase,50hz
    380Volt,3phase,60hz

    We offer free pipe and valves for installation and installation diagram

    Technical Specifications of screw air compressor

    Model Air Flow (m³/min) Motor Power Noise Outlet Diameter Dimension Weight
    7bar 8bar 10bar 13bar kw dB inch W*D*H (mm) kg
    YD-7.5A 1.0 0.8 0.5 0.4 5.5 65 G3/4'' 780*680*800 300
    YD-10A 1.1 1.0 0.85 0.7 7.5 65 G3/4'' 780*680*800 320
    YD-15A 1.8 1.65 1.5 1.3 11 65 G3/4'' 1100*800*980 400
    YD-20A 2.4 2.2 2.1 1.8 15 68 G3/4'' 1100*800*980 430
    YD-25A 3.1 3.0 2.7 2.3 18.5 68 G1'' 1250*870*1180 590
    YD-30A 3.8 3.6 3.2 2.5 22 68 G1'' 1250*870*1180 650
    YD-40A 5.3 5.0 4.3 3.6 30 69 G1'' 1250*870*1180 750
    YD-50A 6.6 6.2 5.7 4.6 37 69 G11/2'' 1540*950*1290 880
    YD-60A 8.0 7.7 6.9 6.0 45 70 G11/2'' 1540*950*1290 1000
    YD-75A/W 10.5 9.8 8.7 7.3 55 70 G2'' 1600*1150*1420 1500
    YD-100A/W 13.6 13.0 11.3 10.1 75 72 G2'' 2010*1260*1460 1900
    YD-125A/W 16.2 15.4 13.2 11.2 90 72 DN50 2010*1260*1460 2500
    YD-150A/W 20.8 19.5 16.5 13.7 110 73 DN65 2300*1600*1790 2800
    YD-175A/W 24.0 23.0 20.0 15.5 132 74 DN65 2300*1600*1790 3000
    YD-220A/W 27.8 26.0 23.5 19.5 160 75 DN80 2500*1700*1850 3500
    YD-250A/W 32.5 31.0 26.0 21.6 185 76 DN80 2500*1700*1850 3800
    YD-270A/W 34.5 33.0 28.0 23.5 200 77 DN80 2500*1700*1850 4200
    YD-300A/W 38.0 36.5 32.0 27.0 220 78 DN100 2800*1900*1950 4800
    YD-350A/W 43.0 40.5 36.5 32.0 250 80 DN100 2800*1900*1950 5200
    YD-500A/W 76.0 75.3 65.4 59.0 400 83 DN125 4200*2200*2240 8200
    Remarks:
    1. "A" represents air cooling, and "W" represents water cooling;
    2. working ambinent temperature: -5℃-45℃;
    3. exhausting air temperature ≤ working ambinent temperature +10℃-15℃;
    4. starting mode: Y-△;
    5. exhausting oil content: ＜3ppm;
    6. certificate: CE/ISO9001/ASME;
    7. voltage: 380V/220V/400V/440V/415V
