Description
Product description
Model
Air Flow (m³/min)
Motor Power
Noise
Outlet Diameter
Dimension
Weight
7bar
8bar
10bar
13bar
kw
dB
inch
W*D*H (mm)
kg
YV-10A
1.1
1.0
0.85
0.7
7.5
65
G1''
960*680*960
280
YV-15A
1.8
1.65
1.5
1.3
11
65
G1''
1050*830*1240
380
YV-20A
2.4
2.2
2.1
1.8
15
68
G1''
1050*830*1240
380
YV-25A
3.1
3.0
2.7
2.3
18.5
68
G1''
1200*830*1290
480
YV-30A
3.8
3.6
3.2
2.5
22
68
G1''
1200*830*1290
480
YV-40A
5.3
5.0
4.3
3.6
30
69
G11/2''
1300*1000*1540
710
YV-50A
6.6
6.2
5.7
4.6
37
69
G11/2''
1300*1000*1540
710
YV-60A
8.0
7.7
6.9
6.0
45
70
G11/2''
1500*1160*1700
990
YV-75A
10.5
9.8
8.7
7.3
55
70
G11/2''
1500*1160*1700
990
YV-100A
13.6
13.0
11.3
10.1
75
72
G2''
1700*1180*1800
1300
YV-125A
16.2
15.4
13.2
11.2
90
72
DN50
1850*1200*1900
1400
YV-150A
20.8
19.5
16.5
13.7
110
73
DN65
2250*1260*2055
1560
Remarks:
1. working ambinent temperature: -5℃-45℃;
2. exhausting air temperature ≤ working ambinent temperature +10℃-15℃;
3. starting mode: variable frequency starting;
4. exhausting oil content: ＜3ppm;
5. certificate: CE/ISO/SGS/TUV/ASME;
6. voltage: 380V/230V/220V/400V/440V/415V/460V
Product Details
